Fuse 14x51 gRL/gS 690VAC/440VDC with striker 35A

    Fuse 14x51 gRL/gS 690VAC/440VDC with striker 35A

    SIBA
    5012634.35.0
    Product available on request

    Product Request:

    Fuse 14x51 gRL/gS 690VAC/440VDC with striker 35A

    Fuse 14x51 gRL/gS 690VAC/440VDC with striker 35A

    do not include special characters

    * Required fields



    This product is only sold in boxes of 10 pcs

    This product has a minimum quantity of 10 and sold by 10

    Download

    Catalog Datasheet
    Class
    gRL/gS
    Rated current In (A)
    35
    Rated Voltage Un AC (V)
    690
    Rated break.capacity I1 AC (A)
    200000
    Voltage of total I2t test
    700
    Weight (g)
    22
    Format
    Cylindrical
    Dimension
    14x51mm
    Pre-arcing I2t value (A2s)
    370
    Total I2t value (A2s)
    2800
    Homologations
    IEC & UL
    Power loss (W)
    4,2
    Rated Voltage Un DC (V)
    440
    Rated break.capacity I1 DC (A)
    30000
    Time costant L/R (ms)
    30

    Alternatives

    Fuse 14x51 gRL/gS 690VAC/440VDC 35A
      Available
      gRL/gS fuses

      Fuse 14x51 gRL/gS 690VAC/440VDC 35A

      SIBA SIBA
      5012434.35.0
      Class
      gRL/gS
      Rated current In (A)
      35
      Rated Voltage Un AC (V)
      690
      Rated break.capacity I1 AC (A)
      200000
      Voltage of total I2t test
      700
      Format
      Cylindrical
      Dimension
      14x51mm
      Pre-arcing I2t value (A2s)
      370
      Total I2t value (A2s)
      2800
      Homologations
      IEC & UL
      Power loss (W)
      4,2
      Rated Voltage Un DC (V)
      440
      Rated break.capacity I1 DC (A)
      30000
      Time costant L/R (ms)
      30

      Product available on request

      Accessories

      Fuse holder 14x51 1+N 750VAC/DC UL switch (fusing+ presence)
        Available
        for Cylindrical fuses

        Fuse holder 14x51 1+N 750VAC/DC UL switch (fusing+ presence)

        485221.0.0
        Rated current In (A)
        50
        Rated Voltage Un AC (V)
        690
        Homologations
        IEC
        Fuses format
        Cylindrical
        Fuses dimension
        14x51mm
        Rated Voltage Un DC (V)
        750
        Number of phase
        1+N
        Max power dissipation (W)
        5

        Product available on request

        Fuse holder 14x51 4p 75VAC/DC UL switch (only fusing)
          Available
          for Cylindrical fuses

          Fuse holder 14x51 4p 75VAC/DC UL switch (only fusing)

          485231.0.0
          Rated current In (A)
          50
          Rated Voltage Un AC (V)
          690
          Homologations
          IEC
          Fuses format
          Cylindrical
          Fuses dimension
          14x51mm
          Rated Voltage Un DC (V)
          750
          Number of phase
          4
          Max power dissipation (W)
          5

          Product available on request

          Fuse holder 14x51 1+N 750VAC/DC switch (only fusion)
            Available
            for Cylindrical fuses

            Fuse holder 14x51 1+N 750VAC/DC switch (only fusion)

            485227.0.0
            Rated current In (A)
            50
            Rated Voltage Un AC (V)
            690
            Homologations
            IEC
            Fuses format
            Cylindrical
            Fuses dimension
            14x51mm
            Rated Voltage Un DC (V)
            750
            Number of phase
            1+N
            Max power dissipation (W)
            5

            Product available on request

            Fuse holder 14x51 4p 750VAC/DC UL switch (fusing+presence)
              Available
              for Cylindrical fuses

              Fuse holder 14x51 4p 750VAC/DC UL switch (fusing+presence)

              485225.0.0
              Rated current In (A)
              50
              Rated Voltage Un AC (V)
              690
              Homologations
              IEC
              Fuses format
              Cylindrical
              Fuses dimension
              14x51mm
              Rated Voltage Un DC (V)
              750
              Number of phase
              4
              Max power dissipation (W)
              5

              Product available on request

              Fuse holder 14x51 3p 750VAC/DC UL switch (only fusing)
                Available
                for Cylindrical fuses

                Fuse holder 14x51 3p 750VAC/DC UL switch (only fusing)

                485229.0.0
                Rated current In (A)
                50
                Rated Voltage Un AC (V)
                690
                Homologations
                IEC
                Fuses format
                Cylindrical
                Fuses dimension
                14x51mm
                Rated Voltage Un DC (V)
                750
                Number of phase
                3
                Max power dissipation (W)
                5
                $54.95
                Fuse holder 14x51 2p 750VAC/DC UL switch (fusing+ presence)
                  Available
                  for Cylindrical fuses

                  Fuse holder 14x51 2p 750VAC/DC UL switch (fusing+ presence)

                  485222.0.0
                  Rated current In (A)
                  50
                  Rated Voltage Un AC (V)
                  690
                  Homologations
                  IEC
                  Fuses format
                  Cylindrical
                  Fuses dimension
                  14x51mm
                  Rated Voltage Un DC (V)
                  750
                  Number of phase
                  2
                  Max power dissipation (W)
                  5

                  Product available on request

                  Fuse holder 14x51 1p 750VAC/DC switch (only fusion)
                    Available
                    for Cylindrical fuses

                    Fuse holder 14x51 1p 750VAC/DC switch (only fusion)

                    485226.0.0
                    Rated current In (A)
                    50
                    Rated Voltage Un AC (V)
                    690
                    Homologations
                    IEC
                    Fuses format
                    Cylindrical
                    Fuses dimension
                    14x51mm
                    Rated Voltage Un DC (V)
                    750
                    Number of phase
                    1
                    Max power dissipation (W)
                    5
                    $22.25
                    Fuse holder 14x51 2p 750VAC/DC UL switch (only fusing)
                      Available
                      for Cylindrical fuses

                      Fuse holder 14x51 2p 750VAC/DC UL switch (only fusing)

                      485228.0.0
                      Rated current In (A)
                      50
                      Rated Voltage Un AC (V)
                      690
                      Homologations
                      IEC
                      Fuses format
                      Cylindrical
                      Fuses dimension
                      14x51mm
                      Rated Voltage Un DC (V)
                      750
                      Number of phase
                      2
                      Max power dissipation (W)
                      5

                      Product available on request

                      Fuse holder 14x51 3+N 750VAC/DC UL switch (fusing+ presence)
                        Available
                        for Cylindrical fuses

                        Fuse holder 14x51 3+N 750VAC/DC UL switch (fusing+ presence)

                        485224.0.0
                        Rated current In (A)
                        50
                        Rated Voltage Un AC (V)
                        690
                        Homologations
                        IEC
                        Fuses format
                        Cylindrical
                        Fuses dimension
                        14x51mm
                        Rated Voltage Un DC (V)
                        750
                        Number of phase
                        3+N
                        Max power dissipation (W)
                        5

                        Product available on request

                        Fuse holder 14x51 690VAC/750VDC UL 1P with microswitch
                          Available
                          for Cylindrical fuses

                          Fuse holder 14x51 690VAC/750VDC UL 1P with microswitch

                          5105805.1S.0
                          Rated current In (A)
                          50
                          Rated Voltage Un AC (V)
                          690
                          Homologations
                          IEC & UL
                          Fuses format
                          Cylindrical
                          Fuses dimension
                          14x51mm
                          Rated Voltage Un DC (V)
                          750
                          Number of phase
                          1
                          Max power dissipation (W)
                          5
                          $25.96
                          Fuse holder 14x51 690VAC/750VDC UL 2P with microswitch
                            Available
                            for Cylindrical fuses

                            Fuse holder 14x51 690VAC/750VDC UL 2P with microswitch

                            5105805.2S.0
                            Rated current In (A)
                            50
                            Rated Voltage Un AC (V)
                            690
                            Homologations
                            IEC & UL
                            Fuses format
                            Cylindrical
                            Fuses dimension
                            14x51mm
                            Rated Voltage Un DC (V)
                            750
                            Number of phase
                            2
                            Max power dissipation (W)
                            5

                            Product available on request

                            Fuse holder 14x51 3+N 750VAC/DC UL switch (only fusing)
                              Available
                              for Cylindrical fuses

                              Fuse holder 14x51 3+N 750VAC/DC UL switch (only fusing)

                              485230.0.0
                              Rated current In (A)
                              50
                              Rated Voltage Un AC (V)
                              690
                              Homologations
                              IEC
                              Fuses format
                              Cylindrical
                              Fuses dimension
                              14x51mm
                              Rated Voltage Un DC (V)
                              750
                              Number of phase
                              3+N
                              Max power dissipation (W)
                              5

                              Product available on request

                              Fuse holder 14x51 690VAC/750VDC UL 3P with microswitch
                                Available
                                for Cylindrical fuses

                                Fuse holder 14x51 690VAC/750VDC UL 3P with microswitch

                                5105805.3S.0
                                Rated current In (A)
                                50
                                Rated Voltage Un AC (V)
                                690
                                Homologations
                                IEC & UL
                                Fuses format
                                Cylindrical
                                Fuses dimension
                                14x51mm
                                Rated Voltage Un DC (V)
                                750
                                Number of phase
                                3
                                Max power dissipation (W)
                                5

                                Product available on request
